#0002

A double-DINGLE, four-gear, light-duty rigid mountain bike delight designed for bike camping and city cruising.


THE FRAMESET

Mixing it up with a double dingle speed built upon our FGATB foundation, this baby utilizes 135mm x 10mm QR axles for both wheels, a set of Velocity Blunt 35s rims laced to Surly Single Speed hubs, and two White Industries Double Freewheels so future rider Jon can dial in just the right singlespeed gearing for any terrain he decides to tackle.

Jon, an artist and printmaker, kept the input coming to nail down every detail and ensure his bike is a lifetime build– from form down to nitty gritty function. This labor of love features heavily shaped bronze fillet brazed construction and a custom cheetah-print front fork crown, as well as a host of premium components hand-picked by Jon.

Mixing Columbus and Tange tubing ensures this bike is light and compliant for long days in the saddle, offering the robustness to handle a bike camping load while still being agile enough for the demands of everyday city riding. Jon and I bonded around a love for six-bolt stems the first day we met, so I knew when he chose the Doom Legal Drinker bar for his build that we needed a custom stem for this frame design. Our tallboy stem replaces all those ring-shaped things and affords just enough panache to piss off the weight weenies in the room. This build is headed to paint soon, so check in to see it take its final form.

  • Reach - 452mm

    Stack - 650mm

    Headtube Angle - 70 deg

    Headtube Length - 206mm

    Seattube Angle - 71.4 deg

    Seattube Length - 689mm

    Bottom Bracket Drop - 60mm

    Bottom Bracket Height - 318mm

    Chainstay Length - 460 (slammed)

    Axle - 135mm x 10mm QR

    Maximum Tire Width - 2.6

    Maximum Chainring - 34t

  • Fork Axle to Crown - 435mm

    Fork Rake - 60mm

    Axle - 135mm x 10mm QR

  • • Extra-Long Track Dropouts

    • Sliding Rear I.S. Disc Tab for Multiple Gearing Options

    • Double Dinglespeed FTW

    • Custom Tallboy 6-bolt Stem with Extra-Wide Clamp Built for Doom Legal Drinker Bar

    • Custom Cheetah Print Mid-Sendtury Fork

    • Custom Wheelset by Elevation Wheel Company
