MADE
2024
A little weird and a lot awesome: our MADE 2024 lineup features four totally disparate bikes that showcase the eccentric Good Grief way of gettin’ it.
**MADE SPECIAL**
Save $200 when you place your build desposit with us in person at Made Portland, August 23-24-25.
Bike #0003
”CROP TOP”
A purpose-built bikepacking beauty made to haul stuff, not ass. The long rear end and raked front give this bike a Cadillac-like feel that’s a dream on dusty stretches of gravel, but still able to tackle singletrack while loaded with nimble grace.
-
Reach - 408mm
Stack - 700mm
Headtube Angle - 70 deg
Headtube Length - 248mm
Seattube Angle - 70 deg
Seattube Length - 500mm
Bottom Bracket Drop - 70mm
Chainstay Length - 510mm
Axle - 142mm x 12mm TA & 100mm x 15mm TA
Maximum Tire Width - 2.5
Maximum Chainring - 38t
-
Fork Axle to Crown - 435mm
Fork Rake - 60mm
Axle - 100mm x 15mm TA w/Dynamo Routing
-
• Double Top Tube
• Custom Wide Crown Half Truss Fork
• Custom Permanent Front and Rear Racks
• Custom No-projection Stem
• UDH Rear Dropouts
More details and photos
—> Bike #0003
Bike #0005
The goal was simple: take a beloved geometry, lighten it up, then make it stout enough to handle the kitty litter descents that the Pikes Peak region is known for. Kitted out with a Pike Ultimate 140mm fork, externally-routed mechanical components, and a killer custom frame bag by Dark Void (made from upcycled Ikea bags!), this bikepacking machine ensures its own capability through its industrious (and repairable) concept.
-
Reach - 502mm
Stack - 664mm
Headtube Angle - 66 deg
Headtube Length - 126mm
Seattube Angle - 74 deg
Seattube Length - 460mm
Bottom Bracket Drop - 72mm
Chainstay Length - 438mm
Axle - 148mm x 12mm TA & 110mm x 15mm TA
Maximum Tire Width - 2.4
Maximum Chainring - 36t
-
Fork Axle to Crown - 552mm
Fork Offset - 44mm
-
• UDH Dropouts
• 15 deg downtube bend for extra framebag and waterbottle space
• 44mm Headtube
• Stealth Dropper Routing
• Custom Dark Void Framebag
• Paul Comp Levers and Klampers
• Custom party patina finish
More details and photos
—> Bike #0005
PRODUCTION FRAME
”SCORCHED EARTH”
This frame isn’t about FKT’s, it’s about fun. Rediscover the thrill of your favorite routes without stopping pedaling. Or, customize your frame with a rear brake mount for singlespeed– or anything else you can dream up. Non-suspension-corrected geometry ensures you get a unique ride that’s not your average frankenbike. It might just become your favorite bike for EVERYTHING.
-
Reach - 440mm
Stack - 635mm
Headtube Angle - 70 deg
Headtube Length - 205mm
Seattube Angle - 71.5 deg
Seattube Length - 505mm
Bottom Bracket Drop - 60mm
Chainstay Length - 460mm
Maximum Tire Width - 2.6
Maximum Chainring - 34
-
Fork Axle to Crown - 420mm
Fork Rake - 60mm
Axle - 135mm x 10mm QR
Dropouts - Custom 10mm QR
-
• Dyed Metal "paint" job
• Xtra-Wide unicrown fork for "feet up" descending
• No-yoke design
• Custom xtra-long dropouts for all the gearing options
More details and photos
—> Scorched Earth
BIKE #0001
An understated shred sled clad in bronze and steel designed for easy getting up...and fast getting down. We translated a much-loved 27.5” geometry to 29”, with a frame spec’d with oversized Tange and Dedacciai tubing that would happily boast a mid-heavyweight label.
-
Reach - 484mm
Stack - 624mm
Headtube Angle - 66 deg
Headtube Length - 102mm
Seattube Angle - 74 deg
Seattube Length - 390mm
Bottom Bracket Drop - 60mm
Bottom Bracket Height - 312mm
Chainstay Length - 437mm
Axle - 148mm (boost) w/UDH
Maximum Tire Width - 29” x 2.4”
-
RockShox Lyric 140mm Travel
-
• UDH Rear Dropouts
• 180mm Integrated Post Mount Rear Brake
• Rear Brake Cable Braze-ons Only, Wireless SRAM Dropper and Groupset for Clean Aesthetic
• Custom 40mm Stem with Extra Stack for Minimal Spacers
• Custom Machined IS42/52 Headset
• Mix of Tange and Dedacciai Tubing
• No-Yoke Rear End
More details and photos
—> Bike #0001
